DT06-6S / 7062G-1.5-21 6-Pin Female Auto Connector

1. Product Type Features

This DT06-6S / 7062G-1.5-21 automotive female connector is a high-performance industrial-grade automotive wiring accessory with standard TE internal part number DT06-6S-E003 and official description PLG, 6P, GRY, N, CAP. It adopts a professional rectangular overall outline design, purely dedicated to automotive circuit connection without any mixed and hybrid functional structure, focusing on single, safe and stable circuit conduction performance. The whole set is standard housing specially matched for female terminals, with built-in full sealable waterproof and dustproof integrated sealing structure, perfectly adapting to complex under-hood and chassis harsh working environments. The primary locking structure is integrally injection-molded inside the housing body, with firm clamping and strong anti-loosening ability. Adopting mature wire-to-wire interconnection system, it can realize stable butt joint and conduction between two sections of automotive wires and cables, fully matching formal automotive wiring harness production, original vehicle assembly and after-sales maintenance replacement scenarios, and meeting international automotive accessory industry design specifications.

2. Configuration Features

The connector adopts scientific modular structural configuration, equipped with practical end cap optimization modification design to enhance overall sealing and anti-dust protection performance. There is no blank cavity position inside the shell, and the internal layout is fully utilized without space waste. It is equipped with a standard 6-position core wiring channel, reasonably arranged in 2 neat rows, with uniform spacing and independent partitioning of each circuit cavity. The internal wiring channels do not interfere with each other, effectively avoiding hidden dangers such as signal crosstalk, current mutual interference and short circuit faults during long-term working operation. The standardized row layout structure is convenient for automated batch assembly on wiring harness production lines, and also supports rapid manual plugging and maintenance in auto repair workshops. The overall configuration is compact and regular, which is convenient for enterprise unified inventory management and large-scale centralized procurement and distribution.

3. Electrical Characteristics

This connector has excellent comprehensive electrical performance and wide voltage adaptation range. The nominal voltage architecture covers mainstream automotive low-voltage standards of 12V, 24V and 48V, fully compatible with various passenger vehicles, commercial vehicles and engineering vehicle on-board power supply systems. The stable operating voltage can reach 250V VDC and 250V VAC, which can safely bear long-term stable power supply and signal transmission of vehicle electrical modules. The single contact is designed with high load-bearing capacity, with a maximum safe contact current rating up to 13A, which can steadily support high-power automotive electrical components, sensors, power distribution modules and core circuit power supply work. The internal conductive structure has low contact resistance, good electrical conductivity and stable thermal conductivity, no heating, no power loss, ensuring continuous and safe operation of automotive electrical circuits without electrical failure risks.

4. Body Features

The connector shell is integrally injection-molded with high-strength automotive special engineering plastic materials, with uniform and smooth surface, no burrs, no deformation and no color difference. The primary finished color is industrial practical gray, resistant to dirt and corrosion, and suitable for long-term use in dirty and humid vehicle environments. It adopts a standard 180° cable exit angle design, which makes the wiring harness routing straight and tidy, saves the internal installation space of the vehicle body, avoids wire winding and extrusion damage, and optimizes the overall wiring layout efficiency. The shell has strong compression resistance, impact resistance, aging resistance and oil corrosion resistance, can resist engine oil, sediment, humid gas and ultraviolet erosion, and will not crack or age after long-term vibration and temperature alternation inside the vehicle.

5. Contact Features

Matched with high-precision professional socket-type conductive contacts, adopting Size 16 standard contact specification, and the precise mating pin diameter is controlled at 1.59 mm to ensure accurate and tight docking with supporting male terminals. The contacts are made of high-purity high-conductivity conductive materials, with excellent oxidation resistance, corrosion resistance and thermal stability, maintaining stable elastic contact performance in high-temperature, humid and dusty vehicle working conditions. The built-in elastic clamping structure has uniform and lasting clamping force, which can firmly lock the butted terminals, effectively prevent terminal retreat, loosening and virtual connection caused by long-term vehicle bump vibration, and ensure uninterrupted stable signal and current transmission all the year round.

6. Dimensions

Produced with high-precision automotive professional precision molds, all dimensional tolerances are strictly controlled within the industry standard range. The overall structure is regular and compact, fully matching the installation space requirements of narrow gaps in vehicle engine compartments, chassis and body electrical boxes. The internal cavity spacing, row spacing and interface size are completely consistent with the original DT series matching standards, with high interchangeability. It can be directly replaced and installed with the original model without modifying wiring harness fixtures, assembly tools and production molds, which effectively saves the procurement cost and time cost of batch supporting for enterprises.

7. Usage Conditions

This connector has super strong environmental adaptability, supporting an ultra-wide professional operating temperature range of -55°C to 125°C, which can easily cope with extreme low-temperature frost and severe cold in northern regions, and also withstand high-temperature heat radiation and baking in summer engine compartments. With fully sealed waterproof and dustproof performance, it can effectively isolate rainwater splashing, high-pressure water washing, mud immersion and dust accumulation. It is suitable for long-term stable outdoor exposed wiring, engine peripheral wiring, chassis low-voltage circuits and other harsh position connection work, and will not fail or age due to environmental changes.

8. Summary of Key Attributes

6-position two-row rectangular gray female automotive sealed connector, model DT06-6S / 7062G-1.5-21, complete female terminal housing, full waterproof seal, integrated housing locking, wire-to-wire connection mode, wide voltage 12/24/48V compatible, 250V high voltage resistance, 13A high current bearing, 1.59mm precision socket contacts, 180° straight wire outlet, high-strength anti-aging plastic housing, polarization anti-misinsertion design, terminal position assurance function, strain relief realized by supporting accessories, ultra-wide temperature resistance, automotive professional grade, vibration resistance and corrosion resistance, cost-effective OEM and aftermarket general wiring harness matching parts.

9. Application Guidance

Widely applicable to various passenger cars, trucks, new energy vehicles, engineering machinery and agricultural machinery equipment. It is mainly used for engine peripheral power signal wiring, chassis waterproof sensor connection, vehicle body control module wiring, outdoor lamp circuit assembly, engineering vehicle electrical system matching and other core scenarios. It is the preferred supporting part for OEM complete vehicle factory assembly, wiring harness factory finished product processing, auto repair shop daily circuit maintenance and replacement, and mechanical equipment electrical renovation wiring.

10. Installation Notes

Check the integrity of the internal sealing ring and the elasticity of the socket contacts before assembly. Align the polarization positioning structure accurately to avoid misinsertion and reverse insertion. Push firmly until the integrated locking buckle clicks to confirm full locking in place. Do not pull the wiring harness violently or bend the wire sharply at the connector root. Do not overload beyond 13A maximum current to prevent overheating safety hazards. Avoid long-term contact with strong chemical corrosive liquids. After installation, shake slightly to check for looseness to ensure long-term stable waterproof and conductive operation.

11. Compliance and Standards

All materials meet international automotive environmental protection and flame-retardant safety standards, passing UL 94 flame retardant grade testing and SAE J2030 automotive industry specification certification. The waterproof, mechanical and electrical performance have passed third-party professional testing, fully compliant with automotive low-voltage wiring harness accessory safety regulations. All products are packed in moisture-proof, dust-proof and shockproof export cartons, meeting cross-border long-distance transportation and large warehouse storage standards, with reliable quality and complete compliance certificates.
