Nominal Voltage Architecture (V): 12
Connector & Housing Type : Housing for Female Terminals
Number of Positions : 2
Sealable : Yes
Operating Temperature Range : -40 – 130 °C [ -40 – 266 °F ]
| Connector Shape | Rectangular |
| Mixed & Hybrid Connector | No |
| Connector & Housing Type | Housing for Female Terminals |
| Sealable | Yes |
| Primary Locking Feature | Locking Lance |
| Connector System | Wire-to-Board |
| Connector & Contact Terminates To | Wire & Cable |
| Number of Positions | 2 |
| Number of Rows | 1 |
| Operating Voltage (VDC) | 12 |
| Nominal Voltage Architecture (V) | 12 |
| Cable Exit Angle (°) | 180 |
| Primary Product Color | Black |
| Contact Type | Receptacle |
| Contact Size | 2.8 mm |
| Mating Tab Width | 2.8 mm (0.11 in) |
| Mating Alignment | With |
| Mating Alignment Type | Polarizing Slot |
| Terminal Position Assurance | No |
| Strain Relief | Without |
| Connector Mounting Type | Cable Mount (Free-Hanging) |
| Housing Material | PBT GF30 |
| Centerline (Pitch) | 9.7 mm (0.382 in) |
| Connector Height | 26.5 mm (1.043 in) |
| Product Length | 30.7 mm (1.209 in) |
| Product Width | 33.8 mm (1.33 in) |
| Operating Temperature Range | -40 to 130 °C (-40 to 266 °F) |
| Operating Temperature (Max) | 130 °C (266 °F) |
