Nominal Voltage Architecture (V): 12 | 24 | 48
Connector & Housing Type : Housing for Male Terminals
Number of Positions : 4
Sealable : Yes
Operating Temperature Range : -40 – 125 °C [ -40 – 257 °F ]
| Product Type Features | |
| Connector Shape | Rectangular |
| Mixed & Hybrid Connector | No |
| Connector & Housing Type | Housing for Male Terminals |
| Sealable | Yes |
| Primary Locking Feature | Integrated in Housing |
| Connector System | Wire-to-Wire |
| Connector & Contact Terminates To | Wire & Cable |
| Configuration Features | |
| Number of Positions | 4 |
| Number of Rows | 1 |
| Electrical Characteristics | |
| Operating Voltage (VDC) | 24 |
| Nominal Voltage Architecture (V) | 12 | 24 | 48 |
| Body Features | |
| Cable Exit Angle (°) | 180 |
| Primary Product Color | Black |
| Contact Features | |
| Contact Type | Tab |
| Contact Size | 1.5mm |
| Mating Tab Width | 1.5 mm [.06 in] |
| Contact Current Rating (Max) (A) | 14 |
