Company Model: RH7033C-3.5-21
Industry Benchmark / OE Reference Numbers: 881742-1 / 85205-1
Core Specifications:
Number of Positions: 3
Terminal Size: 2.8 mm
Maximum Current: 30A
Rated Voltage: 12V DC
Material & Color:
Housing Material: PBT GF30
Color: Black
Terminal Material: Brass
Operating Temperature: -40°C ~ +130°C (-40°F ~ +266°F)
| Part Number | RH7033C-3.5-21 |
| Industry Cross-Reference (OE No.) | 881742-1 / 85205-1 |
| Core Specifications | |
| Number of Positions | 3 |
| Terminal Size | 2.8 mm |
| Maximum Current | 30A |
| Rated Voltage | 12V DC |
| Housing Material | PBT GF30 |
| Color | Black |
| Terminal Material | Brass |
| Operating Temperature | -40°C ~ +130°C (-40°F ~ +266°F) |
| Certifications | ISO 9001, CE |
| Target Market | North America (USA, Mexico), South America (Brazil, Argentina), Europe (Germany, Poland), Southeast Asia (Thailand, Indonesia) |
| Target Audience | Automotive wiring harness manufacturers, OEM/ODM auto parts suppliers, automotive repair parts wholesalers, MRO purchasers |
| Applicable Models (Cars/Machinery) | Suitable for models using TE AMP Junior Power Timer series connectors; commonly found in GM, Volkswagen, Toyota, Hyundai and other mainstream models for power circuits, sensor harnesses, and lighting wiring systems |
| Key Features | ① 3-Pin single-row layout, 5mm pitch, 2.8mm high-current terminals rated up to 30A; ② PBT GF30 glass-fiber reinforced housing, high-temperature resistant (-40°C~130°C), chemical resistant; ③ Sealable design, waterproof and dustproof, suitable for harsh engine bay environments; ④ Polarizing slot anti-mismating design ensures reliable installation; ⑤ Wire-to-Wire connection, Cable Mount free-hanging installation; ⑥ 100% compatible with TE AMP 881742-1 / 85205-1 original specifications, direct replacement; ⑦ Manufactured in ISO 9001 certified facility, CE certified, consistent quality |
| Product Description | The RH7033C-3.5-21 is a 3-position automotive wire-to-wire connector housing compatible with TE Connectivity AMP Junior Power Timer series (881742-1 / 85205-1). Constructed from PBT GF30 glass-fiber reinforced housing in black, it features a 2.8mm contact size with a maximum current rating of 30A at 12V DC, and operates reliably across a wide temperature range of -40°C to +130°C. The sealable design with polarizing slot ensures secure, mistake-proof mating in high-vibration and moisture-prone automotive environments. Widely applied in power circuits, sensor harnesses, and lighting wiring systems across mainstream vehicle platforms. Factory-direct supply with ISO 9001 quality management and CE certification. |
